Part Number: AM V3 N
Category: Electrical
| Brand | SELEC |
| Model Number | AM V3 N |
| Made in | India |
| Lead Time | SAME DAY DISPATCH |
Lead Time : Same Day Dispatch
Weight : 0.00 kg
Package Dimensions :
| Measuring Parameter | Under Current & Over Current |
| Electrical Connection | 1Ø-2W |
| Display | 3 Digits Liquid Crystal Display With Backlight |
| CT Setting | CT Primary: 1A / 5A – 999A, CT Secondary: 1A / 5A (selectable) |
Time Ranges | Power ON Delay: 0.5–99.9sec, Trip Time Delay: 0–99.9sec, Recovery Time Delay: 0–99.9sec (In Auto Reset Mode), Response Time: <200ms |
| Accuracy | Current: ±1% of Setting ± 2 digits, Time Setting Accuracy: ±5% of Setting ± 200ms |
| Output Contact | 2 X 1 C/O (SPDT) |
| Output Rating | NO: 5A@250V AC, NC: 3A@250V AC |
| Supply Voltage | 85 to 270V AC / DC |
| Size | 35 mm |
| Certification | CE |
