Lead Time : Same Day Dispatch
Weight : 0.00 kg
Package Dimensions :
| Measuring Parameter | Leakage Current Monitoring in 3Ø &; 1Ø Systems |
| Electrical Connection | 1Ø-2W, 3Ø-3W, 3Ø-4W |
| Display | 3 Digits Liquid Crystal Display With Backlight. |
| Trip Setting | 30mA - 30A |
Time Ranges | Power ON Delay: 0.5-99.9sec, Trip Time Delay: 0-99.9sec, Recovery Time Delay: 0-99.9sec |
Accuracy | Current: ± 5% of setting, Recovery Time, Trip Delay, Power ON Delay: ± 5% of Setting + 100 |
| Output Contact | 2 X 1 C / O (SPDT) |
| Output Rating | NC:3A @ 250V AC, NO:5A @ 250V AC |
| Supply Voltage | 230V AC &; 110V AC |
| Size | 35mm |
| Mounting Type | DIN Rail Mount |
| Certification | CE |
